AI Connections
AI connections enable integration with large language models (LLMs) and AI services. They power the AI node in your workflows, enabling intelligent text processing, analysis, and generation.
Supported Providers
| Provider | Models | Features |
|---|---|---|
| OpenAI | GPT-4, GPT-4 Turbo, GPT-3.5 Turbo | Text, Chat, Embeddings |
| Anthropic | Claude 3 Opus, Sonnet, Haiku | Text, Chat |
| Azure OpenAI | GPT-4, GPT-3.5 (hosted on Azure) | Text, Chat, Embeddings |
| Custom | Any OpenAI-compatible API | Varies |
Creating an AI Connection
- Navigate to Connections in the sidebar
- Click New Connection
- Select the AI provider
- Configure API credentials and settings
- Test and save
OpenAI Configuration
Required Settings
| Setting | Description |
|---|---|
| Name | Display name for connection |
| API Key | Your OpenAI API key |
| Organization ID | Optional organization identifier |
Getting Your API Key
- Sign in to OpenAI Platform
- Navigate to API Keys
- Click Create new secret key
- Copy the key (shown only once)
- Paste into connection settings
Model Selection
Available models:
| Model | Best For | Speed | Cost |
|---|---|---|---|
| gpt-4o | Complex reasoning | Medium | High |
| gpt-4-turbo | Complex tasks | Medium | Medium-High |
| gpt-4 | High-quality output | Slow | High |
| gpt-3.5-turbo | Simple tasks | Fast | Low |
Default model: Select the model used when not specified in the AI node.
Advanced Settings
Base URL: Override for custom endpoints:
Default: https://api.openai.com/v1
Custom: https://your-proxy.com/v1
Request timeout: Maximum time for API response (default: 60 seconds)
Max retries: Number of retry attempts on failure (default: 3)
Anthropic Configuration
Required Settings
| Setting | Description |
|---|---|
| Name | Display name for connection |
| API Key | Your Anthropic API key |
Getting Your API Key
- Sign in to Anthropic Console
- Navigate to API Keys
- Click Create Key
- Copy and save the key
- Paste into connection settings
Model Selection
Available models:
| Model | Best For | Speed | Cost |
|---|---|---|---|
| claude-3-opus | Highest quality | Slower | Highest |
| claude-3-sonnet | Balanced | Medium | Medium |
| claude-3-haiku | Fast, simple tasks | Fastest | Lowest |
Advanced Settings
Max tokens: Default maximum response length (can be overridden per request)
Anthropic version: API version header (usually auto-configured)
Azure OpenAI Configuration
Required Settings
| Setting | Description |
|---|---|
| Name | Display name |
| Endpoint | Azure OpenAI resource endpoint |
| API Key | Azure OpenAI API key |
| Deployment Name | Model deployment name |
| API Version | Azure API version |
Getting Azure Credentials
- Create an Azure OpenAI resource
- Navigate to Keys and Endpoint
- Copy Key 1 or Key 2
- Copy the Endpoint URL
- Note your deployment name
Endpoint Format
https://your-resource-name.openai.azure.com/
API Version
Use a supported version:
2024-02-15-preview
2023-12-01-preview
2023-05-15
Deployment Configuration
Azure requires model deployments:
- Deploy models in Azure OpenAI Studio
- Note deployment names
- Use deployment name (not model name) in connection
Custom/Self-Hosted LLMs
OpenAI-Compatible APIs
For models with OpenAI-compatible APIs:
| Setting | Description |
|---|---|
| Base URL | Your LLM endpoint |
| API Key | Authentication key (if required) |
| Model | Model identifier |
Supported providers:
- Ollama
- LM Studio
- vLLM
- Text Generation Inference
- LocalAI
Example: Ollama
Base URL: http://localhost:11434/v1
API Key: (leave empty)
Model: llama2
Connection Settings
Rate Limiting
Configure to respect API limits:
Requests per minute: Maximum requests within a minute window.
Tokens per minute: Maximum tokens (input + output) per minute.
Cost Controls
Set spending limits:
Max cost per request: Fail requests that would exceed cost threshold.
Monthly budget: Track and alert on monthly spend.
Caching
Enable response caching:
Cache duration: How long to cache identical requests.
Cache scope:
- Per workspace
- Per flow
- Disabled
Testing Connections
Test Connection
After configuration:
- Click Test Connection
- Sends a simple request
- Verifies credentials and connectivity
- Reports any errors
Test Prompt
Send a test prompt:
System: You are a helpful assistant.
User: Say "Hello, connection successful!"
Expected response: Confirmation message from the model.
Using AI Connections
In AI Nodes
Select the connection in AI node configuration:
Connection: OpenAI (GPT-4)
Model: gpt-4-turbo (override connection default)
Temperature: 0.7
Max Tokens: 500
Multiple Connections
Create multiple AI connections:
Use cases:
- Different models for different tasks
- Separate cost tracking
- Development vs production
- Fallback options
Security Best Practices
API Key Security
Do:
- Store keys securely (system encrypted)
- Use organization-specific keys
- Rotate keys periodically
- Monitor usage
Don't:
- Share keys between environments
- Expose keys in logs
- Use personal keys for production
Data Privacy
Consider:
- What data is sent to AI
- Provider data retention policies
- Compliance requirements (GDPR, HIPAA)
- On-premise alternatives
Access Control
Recommendations:
- Limit who can create/edit AI connections
- Audit AI usage
- Set spending limits
- Monitor for anomalies
Cost Management
Understanding Costs
AI costs are based on:
- Input tokens: Text sent to the model
- Output tokens: Text generated by model
- Model tier: GPT-4 vs GPT-3.5, etc.
Cost Optimization
Reduce input tokens:
- Shorter prompts
- Only necessary context
- Summarize before sending
Reduce output tokens:
- Request concise responses
- Set max tokens appropriately
- Use cheaper models for simple tasks
Monitor usage:
- Track costs per flow
- Set alerts for thresholds
- Review usage patterns
Troubleshooting
Authentication Errors
"Invalid API key":
- Verify key is correct
- Check key hasn't been revoked
- Ensure key has necessary permissions
Rate Limit Errors
"Rate limit exceeded":
- Reduce request frequency
- Implement delays between calls
- Upgrade API tier if needed
Model Not Found
"Model not found":
- Verify model name is correct
- Check model availability in your region
- Ensure model access is enabled
Timeout Errors
"Request timed out":
- Increase timeout setting
- Reduce prompt/response size
- Check network connectivity
Context Length Errors
"Maximum context length exceeded":
- Reduce input text
- Summarize content first
- Use model with larger context
Examples
OpenAI for Classification
Connection:
Name: OpenAI Classifier
Provider: OpenAI
API Key: sk-xxx...
Default Model: gpt-3.5-turbo
Usage: Fast, inexpensive classification tasks
Claude for Analysis
Connection:
Name: Claude Analyzer
Provider: Anthropic
API Key: sk-ant-xxx...
Default Model: claude-3-sonnet
Usage: Detailed analysis requiring nuance
Azure for Enterprise
Connection:
Name: Enterprise AI (Azure)
Provider: Azure OpenAI
Endpoint: https://company.openai.azure.com
Deployment: gpt-4-production
Usage: Enterprise compliance requirements
Next Steps
- AI Node - Use AI in workflows
- API Connections - General API setup
- Connections Overview - Managing connections
- Building Flows - Complete workflow guide
